MULTI CORE TEFNOR BLENDED FLEXIBLE PVC INSULATED & SHEATHED COPPER CONDUCTOR CABLES IN VOLTAGE 450/ 750 VOLTS. (100MTRS.)
| Nominal Area In Sq. mm | No. of Strands/ Nominal Dia | Max. DC resistance Ohm/km at 20*C | Nominal Insulation thickness mm | Core dia. mm | Nominal Sheath thickness in mm | Nominal Sheath thickness in mm | Nominal Sheath thickness in mm | Overall Diameter in mm (Approx) | Overall Diameter in mm (Approx) | Overall Diameter in mm (Approx) | Current Rating |
| 2 core | 3 core | 4 core | 2 core | 3 core | 4 core | ||||||
| 0.50 | 16/0.2 | 39.00 | 0.60 | 2.20 | 0.90 | 0.90 | 0.90 | 6.20 | 6.60 | 7.20 | 4 |
| 0.75 | 24/0.2 | 26.00 | 0.60 | 2.50 | 0.90 | 0.90 | 0.90 | 6.80 | 7.20 | 7.90 | 7 |
| 1.00 | 32/0.2 | 19.50 | 0.60 | 2.60 | 0.90 | 0.90 | 0.90 | 7.00 | 7.50 | 8.10 | 12 |
| 1.50 | 30/0.2 | 19.50 | 0.60 | 2.60 | 0.90 | 0.90 | 1.00 | 7.60 | 8.10 | 9.00 | 16 |
| 2.50 | 50/0.25 | 7.98 | 0.70 | 3.50 | 1.00 | 1.00 | 1.00 | 9.00 | 9.60 | 10.50 | 22 |
| 4.00 | 56/0.3 | 4.95 | 0.80 | 4.30 | 1.00 | 1.00 | 1.00 | 10.60 | 11.30 | 12.40 | 29 |
| 6 | 84/0.3 | 3.30 | 0.80 | 5.10 | 1.15 | 1.15 | 1.40 | 12.60 | 13.40 | 15.20 | 37 |
| 10 | 140/0.3 | 1.91 | 1.00 | 6.60 | 1.40 | 1.40 | 1.40 | 16.00 | 17.00 | 18.80 | 51 |
| 16 | 126/0.4 | 1.21 | 1.00 | 8.00 | 1.40 | 1.40 | 1.40 | 18.80 | 20.10 | 22.10 | 68 |
| 25 | 196/4.0 | 0.780 | 1.20 | 10.00 | 2.00 | 2.00 | 2.00 | 24.00 | 25.60 | 28.20 | 86 |
| 35 | 276/0.4 | 0.554 | 1.20 | 11.10 | 2.00 | 2.00 | 2.00 | 26.30 | 28.00 | 31.00 | 110 |
| 50 | 396/0.4 | 0.386 | 1.40 | 13.40 | 2.00 | 2.00 | 2.00 | 30.90 | 33.00 | 36.50 | 145 |
